Guide · proportion and fit
How to size a mantel package
Four measurements and one ratio. Get these right and the room reads as designed; get them wrong and it reads as furniture that arrived by accident.
By Scooter M.Published September 2, 2026Last reviewed September 2, 2026
Disclosure: the buy links below are affiliate links. We earn a commission on Amazon purchases at no extra cost to you. It has never changed a ranking on this site, and every roundup here names a unit we think you should skip. How this site is funded.
The rule, stated once
A media console should be about two-thirds the width of the wall it sits on, and wider than the television on top of it. Those two constraints between them decide almost every purchase in this category. Everything else is finish.
The four measurements to take first
- Wall width, from corner to corner or between whatever actually bounds the space. Multiply by 0.66 for your target console width.
- Television width, measured, not calculated — and the distance between its feet, which is frequently the real constraint.
- Floor depth available. A 15.75-inch console plus a walkway is over three feet of room gone.
- Seating distance and eye height. Sit where you will sit. A television centered too high above a console is the most common outcome of not doing this.
| Wall width | Console target (two-thirds) | Practical size |
|---|---|---|
| 8 ft (96 in) | ~64 in | 58–65 in |
| 10 ft (120 in) | ~79 in | 70 in |
| 12 ft (144 in) | ~95 in | 70–80 in, or a console plus flanking storage |
| 14 ft+ (168 in+) | ~110 in | A 70 in console will look lost. Build out with shelving either side |
Quick picks
Ranked. The running cost column is computed from each unit's rated wattage, not quoted from a manufacturer. Tap a row for the full write-up.
| # | Product | Best for | Cost per hour | Price |
|---|---|---|---|---|
| 1 | Walker Edison Reema 70" Reeded TV Stand with Fireplace70 inches long by 23.75 high by 15.75 deep. On the two-thirds rule that suits a wall from about 105 inches wide. | Walls of 11 feet and up | 27.5¢1,500 W · 5,118 BTU | |
| 2 | Duraflame DFI-5010-01 3D Infrared Fireplace Stove24 by 23.4 by 13.1 inches. When a 70-inch console would eat the room, this is what fits instead. | Small rooms and corners | 27.5¢1,500 W · 5,118 BTU |
#ad Buy links are affiliate links — we earn a commission on Amazon purchases at no extra cost to you, and it never changes the ranking. How this site is funded. Running cost is computed at 18.34¢/kWh; see what these actually cost to run.
The height mistake
Most fireplace consoles are 23 to 25 inches tall. A 75-inch television on top of one puts the center of the screen at roughly 46 to 48 inches — which is close to correct for a sofa, where seated eye height is usually 40 to 45 inches.
This is one of the few places where the standard console dimension is genuinely well-chosen. Where it goes wrong is when people wall-mount a television above a console as well, which pushes the screen to 60 inches or higher and gives everyone a stiff neck. If you are mounting, mount low.
What sizing does not change
| Usage | Hours | Heat on (1,500 W) | Flame only (~100 W) |
|---|---|---|---|
| One evening | 4 | $1.10 | $0.07 |
| A week of evenings | 28 | $7.70 | $0.51 |
| A month, 4 hrs a night | 120 | $33.01 | $2.20 |
| A 90-day winter, 4 hrs a night | 360 | $99.04 | $6.60 |
| Per hour | 1 | 27.5¢ | 1.8¢ |
A 60-inch console and an 80-inch console draw the same 1,500 W and cost the same 27.5 cents an hour. Size is a proportion decision, not a heat decision — a point worth holding on to when a wider unit is being sold on a larger coverage figure.
#1 · Walls of 11 feet and up
Walker Edison Reema 70" Reeded TV Stand with Fireplace
70 inches long by 23.75 high by 15.75 deep. On the two-thirds rule that suits a wall from about 105 inches wide.
Published as 70 inches long, 23.75 high, 15.75 deep, at 126 pounds, taking a television up to 80 inches.
Run the two-thirds rule on it: 70 inches wants a wall of at least about 105 inches, or roughly 8 feet 9. On a 12-foot wall it sits comfortably; on a 9-foot wall it is the wall.
The 15.75-inch depth is worth noting in a narrow room — that is over a foot of floor gone before you place anything in front of it.
What it does not do: Walker Edison does not publish a wattage or BTU figure for the insert on the product page. We asked the page and it is not there — so we do not quote one, and neither should anyone else.
Published specs
- Dimensions:
- 70 in L x 23.75 in H x 15.75 in W
- Weight:
- 126 lb
- Max TV:
- Up to 80 in
- Insert:
- 18 in freestanding fireplace insert with remote
- Heat:
- Runs with or without heat
What it costs to run
- 27.5¢/hr on full heat
- $99.04 across a 90-day winter at 4 hrs a night
- 5,118 BTU/hr · 12.5 A on a 120 V circuit
Computed at 18.34¢/kWh (EIA, June 2026). Your rate will differ — work out your own.
#ad We earn a commission on this link at no cost to you. How this is funded. Price shown on the retailer's page.
Specs from: Walker Edison Reema 70 product page — dimensions, TV size, 18 in insert.
#2 · Small rooms and corners
Duraflame DFI-5010-01 3D Infrared Fireplace Stove
24 by 23.4 by 13.1 inches. When a 70-inch console would eat the room, this is what fits instead.
The sizing problem nobody addresses is what to do when the room is genuinely small. Every console in this category is 60 to 70 inches wide, which in a 10-foot room is most of a wall.
At 24 inches wide and 13.1 deep this takes about a third of the footprint, tucks into a corner, and publishes a real heat figure — 5,200 BTU per hour at 120 V and 12.5 A.
You give up the television surface and the storage. In a small room you were probably wall-mounting the television anyway.
What it does not do: It is a freestanding stove, not an insert. It will not fill a masonry opening and it needs floor space plus clearance in front of the glass door.
Published specs
- Heat output:
- 5,200 BTU/hr
- Electrical:
- 120 V, 12.5 A
- Dimensions:
- 24 in W x 23.4 in H x 13.1 in D
- Weight:
- 28.6 lb
- Flame:
- Layered 3D flame effect, five brightness settings
- Safety:
- Overheat shutoff, adjustable digital thermostat
What it costs to run
- 27.5¢/hr on full heat
- $99.04 across a 90-day winter at 4 hrs a night
- 5,118 BTU/hr · 12.5 A on a 120 V circuit
Computed at 18.34¢/kWh (EIA, June 2026). Your rate will differ — work out your own.
#ad We earn a commission on this link at no cost to you. How this is funded. Price shown on the retailer's page.
Specs from: Duraflame DFI-5010-02-3A user manual — 120 V, 12.5 A; Walmart product page — 5,200 BTU, dimensions, weight.
Questions people actually ask
How wide should a TV console be?
About two-thirds the width of the wall, and always wider than the television. For a 10-foot wall that is roughly 79 inches on the ratio, which in practice means the 70-inch console that dominates this category.
How high should a fireplace console be?
Most are 23 to 25 inches, which puts a television's center at roughly seated eye height. That is why the dimension is so consistent across brands — it is genuinely the right answer for a sofa.
What if my room is too small for a 70-inch console?
Wall-mount the television and use a linear wall unit below it, or use a freestanding stove in a corner. Both put a fire in a small room without a piece of furniture consuming most of a wall.
Does console size affect heat output?
No. Every plug-in electric fireplace caps at 1,500 W and about 5,118 BTU per hour regardless of the furniture around it. A wider console gives you a wider flame and the same warmth.
Sources
Every figure on this page is either taken from one of these documents or computed from a formula shown on the page. Nothing here is recalled from memory.
