Roundup · flush installs
The best recessed electric fireplaces
Flush installation is the single biggest upgrade in how a fireplace reads — it turns an appliance into an opening. Which unit you can actually use is decided by one number your wall already has.
By Scooter M.Published September 6, 2026Last reviewed September 6, 2026

Disclosure: the buy links below are affiliate links. We earn a commission on Amazon purchases at no extra cost to you. It has never changed a ranking on this site, and every roundup here names a unit we think you should skip. How this site is funded.
The criterion: your wall already decided this
A standard 2x4 interior wall gives about 3.5 inches of usable cavity, because a nominal 2x4 actually measures 1.5 by 3.5 inches. Units published under about 4 inches deep sit nearly flush in that. Everything deeper needs furring strips, a 2x6 wall, or a built-out chase — which is a construction decision, not a weekend cut.
| Unit | Published depth | Fits a 2x4 bay? | What it needs |
|---|---|---|---|
| R.W.FLAME 36 | 3.86 in | Yes, slight proud edge | Cut and frame |
| R.W.FLAME 60 | 3.85 in | Yes, slight proud edge | Cut, frame, header at this width |
| Touchstone Sideline 50 | 5 1/2 in | No | Furring, 2x6 or a chase |
| Touchstone Sideline Elite 60 | 5 1/2 in | No | Furring, 2x6 or a chase |
| Dimplex Revillusion RBF30 | 12 1/8 in | No — not even close | A purpose-built enclosure |
Why flush is worth the trouble
Recessing removes the single strongest cue that you are looking at an appliance. A hung unit has a visible edge, a shadow line and a bracket, and your eye reads "object on wall". A flush unit has none of those and reads "opening". It is a large difference in perceived quality and it costs nothing extra in the unit itself — only in the work.
It also gets the fireplace out of the room. A unit projecting four or five inches into a walkway is something people brush past; a flush one is not there at all. The full comparison of the two installs is on wall-mounted vs recessed.
Quick picks: recessed units
Ranked. The running cost column is computed from each unit's rated wattage, not quoted from a manufacturer. Tap a row for the full write-up.
| # | Product | Best for | Cost per hour | Price |
|---|---|---|---|---|
| 1 | R.W.FLAME 36" Ultra-Thin Recessed & Wall-Mount Fireplace3.86 inches deep, published. The unit most likely to fit the wall you already have without building anything out. | A standard 2x4 wall, at 36 inches | 27.5¢1,500 W · 5,118 BTU | |
| 2 | R.W.FLAME 60" Ultra-Thin Recessed & Wall-Mount FireplaceIdentical 3.85-inch depth at 60 inches. The install logic you planned at 36 transfers unchanged. | The same install, wider | 27.5¢1,500 W · 5,118 BTU | |
| 3 | Touchstone The Sideline 50The reference linear unit from a company that makes nothing else. At 5.5 inches deep it needs the wall built out. | A recess you are framing anyway | 27.5¢1,500 W · 5,118 BTU | |
| 4 | Touchstone Sideline Elite 60 (80037)A 56-inch flame viewing area in a 59.75-inch unit. The best glass-to-frame ratio here, and the same heater as the cheapest thing on the page. | The largest flame area, once depth is solved | 27.5¢1,500 W · 5,118 BTU | |
| — | Dimplex Revillusion RBF30 30" Built-In Firebox12 1/8 inches deep. This is a built-in firebox for a purpose-built enclosure, and it will not go in a wall.Skip this one | Not a wall recess at all | 27.5¢1,500 W · 5,118 BTU |
#ad Buy links are affiliate links — we earn a commission on Amazon purchases at no extra cost to you, and it never changes the ranking. How this site is funded. Running cost is computed at 18.34¢/kWh; see what these actually cost to run.
The step that is not on any product page
Power inside the cavity. A cord hanging out of a flush-mounted fireplace defeats the entire purpose of recessing it, so a receptacle has to go inside the recess — and that is licensed work in most US jurisdictions. It is routinely the largest line item in the whole project and the most common reason a recess install stalls after the unit has arrived.
Running cost, which recessing does not change
| Usage | Hours | Heat on (1,500 W) | Flame only (~100 W) |
|---|---|---|---|
| One evening | 4 | $1.10 | $0.07 |
| A week of evenings | 28 | $7.70 | $0.51 |
| A month, 4 hrs a night | 120 | $33.01 | $2.20 |
| A 90-day winter, 4 hrs a night | 360 | $99.04 | $6.60 |
| Per hour | 1 | 27.5¢ | 1.8¢ |
Flush or hung, 36 inches or 60, the figures are the same — about 27.5 cents an hour on full heat and roughly $99 across a 90-day winter at four hours a night. Recessing changes nothing electrical.
#1 · A standard 2x4 wall, at 36 inches
R.W.FLAME 36" Ultra-Thin Recessed & Wall-Mount Fireplace
3.86 inches deep, published. The unit most likely to fit the wall you already have without building anything out.
A standard interior wall framed with 2x4 studs gives about 3.5 inches of usable cavity. R.W.FLAME publishes 3.86 inches across its entire recessed range, which is not a coincidence — it is a product decision aimed squarely at that number. The result sits nearly flush with a slight proud edge most people cannot see from a few feet away.
Specs are 750 W low and 1,500 W high at 120 V, a manufacturer figure of 5,100 BTU per hour, a 400 square foot supplemental rating, and 12 flame colors and 12 ember-bed colors across five brightness levels and five speeds.
The con is a contradiction in the manufacturer's own material: the published depth is 3.86 inches while the listing also references 2x6 framing. Those do not sit comfortably together, so confirm the rough-opening requirement with R.W.FLAME before you cut. The warranty is also one year, the shortest here.
What it does not do: No mantel, no surround and no trim for a masonry opening. Recessing it means cutting drywall and, in most homes, running a receptacle inside the cavity.
Published specs
- Heater:
- 750 W low / 1,500 W high
- Electrical:
- 120 V
- Heat output:
- 5,100 BTU/hr (manufacturer figure)
- Depth:
- 3.86 in — thin enough for a 2x4 stud bay
- Coverage:
- Rated by the manufacturer for up to 400 sq ft
- Flame:
- 12 flame colors, 12 ember-bed colors, 5 brightness levels, 5 speeds
- Sizes in the line:
- 30, 36, 42, 50, 60 and 68 in
What it costs to run
- 27.5¢/hr on full heat
- $99.04 across a 90-day winter at 4 hrs a night
- 5,118 BTU/hr · 12.5 A on a 120 V circuit
Computed at 18.34¢/kWh (EIA, June 2026). Your rate will differ — work out your own.
#ad R.W.FLAME is not a program we have joined, so we earn nothing here. How this is funded. Price shown on the retailer's page.
Specs from: R.W.FLAME recessed/wall-mount product page — full specifications.
#2 · The same install, wider
R.W.FLAME 60" Ultra-Thin Recessed & Wall-Mount Fireplace
Identical 3.85-inch depth at 60 inches. The install logic you planned at 36 transfers unchanged.
The strength of this range is consistency. Published dimensions are 60 by 18.1 by 3.85 inches with the same 750/1500 W at 120 V and 60 Hz, the same 400 square foot rating and the same 12-color flame and ember configuration as the 36.
That matters more than it sounds when you are planning a recess. Deciding mid-project that the wall wants 60 inches instead of 36 changes the framing width and nothing else about the approach.
The con at this width is structural rather than dimensional. A 60-inch opening crosses two or three studs, which means a header and cripples rather than a cut between two studs. Full detail on 60-inch inserts.
What it does not do: No mantel and no surround. The published depth is 3.85 in, but the manufacturer's own listing also references 2x6 framing — confirm the rough-opening requirement with R.W.FLAME before you cut a 60-inch hole in anything.
Published specs
- Dimensions:
- 60 in L x 18.1 in H x 3.85 in D
- Heater:
- 750 W low / 1,500 W high
- Electrical:
- 120 V AC, 60 Hz
- Coverage:
- Rated by the manufacturer for up to 400 sq ft
- Flame:
- 12 flame colors, 12 ember-bed colors, 5 speeds, 5 brightness levels
- Control:
- Touchscreen panel and remote, adjustable thermostat
- Warranty:
- 1 year
What it costs to run
- 27.5¢/hr on full heat
- $99.04 across a 90-day winter at 4 hrs a night
- 5,118 BTU/hr · 12.5 A on a 120 V circuit
Computed at 18.34¢/kWh (EIA, June 2026). Your rate will differ — work out your own.
#ad We earn a commission on this link at no cost to you. How this is funded. Price shown on the retailer's page.
Specs from: R.W.FLAME 60 in listing — 60 x 18.1 x 3.85 in, 750/1500 W, 120 V, 400 sq ft; R.W.FLAME recessed / wall-mount range page.
#3 · A recess you are framing anyway
Touchstone The Sideline 50
The reference linear unit from a company that makes nothing else. At 5.5 inches deep it needs the wall built out.
If you are already framing a false wall, a chase or a 2x6 partition, depth stops being the constraint and housing quality becomes the thing worth paying for. Touchstone's whole catalog is fireplaces rather than furniture with a fireplace in it, and the Sideline 50 is the model most linear units get compared against.
Same 1,500 W ceiling as everything else — about 5,118 BTU per hour and 27.5 cents an hour to run.
The con is the 5.5-inch depth shared across the Sideline line, which rules out a plain 2x4 stud bay. Touchstone also publishes less granular numeric detail on its collection pages than the mass-market retailer listings do, so confirm dimensions with the brand before framing.
What it does not do: Recessing needs a framed cavity. Surface-mounting it works but leaves the unit standing proud of the wall, which reads very differently in a small room.
Published specs
- Width:
- 50 in
- Form:
- Recessed or wall-mounted linear unit
- Line:
- The volume seller of the Sideline range
What it costs to run
- 27.5¢/hr on full heat
- $99.04 across a 90-day winter at 4 hrs a night
- 5,118 BTU/hr · 12.5 A on a 120 V circuit
Computed at 18.34¢/kWh (EIA, June 2026). Your rate will differ — work out your own.
#ad We earn a commission on this link at no cost to you. How this is funded. Price shown on the retailer's page.
Specs from: Touchstone electric fireplaces collection — The Sideline 50.
#4 · The largest flame area, once depth is solved
Touchstone Sideline Elite 60 (80037)
A 56-inch flame viewing area in a 59.75-inch unit. The best glass-to-frame ratio here, and the same heater as the cheapest thing on the page.
Published as 59.75 wide by 19.25 high by 5.5 deep, 5,118 BTU per hour, 750 W and 1,500 W settings with a thermostat adjustable from 68 to 88 °F, a 56 by 14 3/8 inch flame viewing area, six flame colors, ten media-bed colors, five intensities, three speeds and an eight-hour timer.
The flame area is the argument. Very little of what you see is bezel, and a visible frame is the strongest cue telling your eye it is looking at an appliance rather than an opening — which is precisely what recessing is meant to eliminate. Pairing a flush install with a near-frameless front is where this shape actually pays off.
Two cons, both already stated but worth repeating: 5.5 inches deep, so the wall gets built out; and the heater is identical to the standard Sideline 60 at a fraction of the price. Every dollar of the difference is buying the front.
What it does not do: The same 5 1/2 in depth problem as the standard Sideline 60, and the same 1,500 W heater. Everything the extra money buys is on the front of the unit.
Published specs
- Dimensions:
- 59 3/4 in W x 19 1/4 in H x 5 1/2 in D
- Heat output:
- 5,118 BTU/hr
- Heater:
- 750 W / 1,500 W, thermostat 68-88 °F
- Flame viewing area:
- 56 in x 14 3/8 in
- Flame:
- 6 flame colors, 10 media-bed colors, 5 intensities, 3 speeds
- Coverage:
- Rated by the manufacturer for up to 400 sq ft
- Extras:
- 8-hour timer, WiFi, plug-in or hardwire
What it costs to run
- 27.5¢/hr on full heat
- $99.04 across a 90-day winter at 4 hrs a night
- 5,118 BTU/hr · 12.5 A on a 120 V circuit
Computed at 18.34¢/kWh (EIA, June 2026). Your rate will differ — work out your own.
#ad Touchstone Home Products is not a program we have joined, so we earn nothing here. How this is funded. Price shown on the retailer's page.
Specs from: Touchstone Sideline Elite 60 (80037) product page; Retailer listing — 59 3/4 x 19 1/4 x 5 1/2 in, 5,118 BTU, 56 in flame area.
Skip this one
Dimplex Revillusion RBF30 30" Built-In Firebox
12 1/8 inches deep. This is a built-in firebox for a purpose-built enclosure, and it will not go in a wall.
Dimplex publishes 31 1/8 by 26 5/8 by 12 1/8 inches at 50 pounds. That depth is more than three times a 2x4 cavity and more than double a 2x6 one, which puts it in a different category from everything else on this page.
It is a skip in a recessed roundup for a mechanical reason, not a quality one — the Revillusion is a genuinely good firebox with a mirror-free viewing area and a herringbone brick interior. But a firebox is framed into a purpose-built enclosure or a surround, the way a real fireplace would be. It is not something you cut into a partition wall.
If you are building an enclosure from scratch, look at it properly — it belongs alongside the log sets versus inserts decision rather than here. If you are cutting into an existing wall, it is the wrong product and no comparison of flame quality changes that.
What it does not do: This is a firebox, not a plug-in wall unit. At 12 1/8 in deep it will not go into a 2x4 or even a 2x6 wall — it needs a purpose-built enclosure. The higher BTU figures require a higher-voltage hardwired supply and a licensed electrician.
Published specs
- Dimensions:
- 31 1/8 in W x 26 5/8 in H x 12 1/8 in D
- Weight:
- 50 lb
- Form:
- Built-in firebox — framed into a wall or a surround, not a stud bay
- Heat output:
- Up to 8,794 BTU/hr on the higher-voltage configuration
- Flame:
- Revillusion mirror-free viewing area with herringbone brick interior
- Heater:
- Fan-forced
What it costs to run
- 27.5¢/hr on full heat
- $99.04 across a 90-day winter at 4 hrs a night
- 5,118 BTU/hr · 12.5 A on a 120 V circuit
Computed at 18.34¢/kWh (EIA, June 2026). Your rate will differ — work out your own.
#ad We earn a commission on this link at no cost to you. How this is funded. Price shown on the retailer's page.
Specs from: Dimplex Revillusion RBF30 owner's manual; Retailer listing — RBF30 dimensions and weight.
Questions people actually ask
How deep does a wall need to be for a recessed electric fireplace?
About 3.5 inches, which is what a standard 2x4 stud wall provides. Units published under about 4 inches deep sit nearly flush. Anything deeper needs furring strips, a 2x6 wall, or a built-out chase.
Can any wall-mount fireplace be recessed?
Most modern linear units are dual-install, but check the published depth first. A unit deeper than about 3.5 inches will not sit flush in a standard wall, and a built-in firebox such as the Dimplex Revillusion at 12 1/8 inches is a different product class entirely.
Is recessing worth the extra work?
Visually, yes — it removes the strongest cue that you are looking at an appliance, and it takes the unit out of the room. Practically it depends on whether you own the house, whether the wall is interior stud framing, and what an electrician quotes for a receptacle inside the cavity.
Do recessed fireplaces heat better than wall-mounted ones?
No. Same 1,500 W and the same roughly 5,118 BTU per hour, and the same running cost. The only real thermal consideration is not burying the heat outlet behind trim or furniture.
Sources
Every figure on this page is either taken from one of these documents or computed from a formula shown on the page. Nothing here is recalled from memory.
- EIA Electric Power Monthly, Table 5.3 — US residential average, June 2026
- R.W.FLAME recessed / wall-mount range — 3.86 in depth, 750/1500 W, 5,100 BTU
- R.W.FLAME 60 in recessed / wall-mount listing — 60 x 18.1 x 3.85 in, 750/1500 W, 120 V
- Touchstone Home Products — electric fireplace range and sizes
- Touchstone Sideline Elite 60 (80037) product page — 59.75 x 19.25 x 5.5 in, 5,118 BTU, 750/1500 W
- Dimplex Revillusion RBF30 owner's manual — built-in firebox installation and ratings
